The TKZM-06 intelligent pulse controller is the core control device of the pulse bag dust collector’s spray cleaning system. Its performance directly determines the dust cleaning efficiency and operation stability of the dust collector. The device uses intelligent microcomputer technology to achieve precise timing control, uses a photoelectric coupler to isolate the main circuit from the output end, and is equipped with a high-power output tube or a bidirectional thyristor to ensure reliability in complex industrial environments such as high dust and strong vibration. The following is an in-depth analysis of the operating secrets of this device from the dimensions of core technology, working mechanism, and operational advantages.

The pulse controller TKZM-06 panel is equipped with a digital display screen, which can display the working order of the electromagnetic pulse valve in real time, and supports custom adjustment of parameters such as pulse width, pulse interval, and cycle interval. At the same time, it is compatible with the differential pressure controller to realize the fixed differential pressure cleaning mode to meet the dynamic adjustment needs under different working conditions.

In terms of technical parameters, the input voltage of the pulse controller TKZM-06 is 220V AC, and the output voltage provides three optional options: AC110V, DC24V, and AC220V to adapt to different solenoid valve specifications. The operating temperature range covers -20℃ to 50℃, and the upper humidity limit is 85%. The output current is up to 900mA, which can drive multiple solenoid valves to work together, and the flexible adaptation of the dust collector structure can be achieved through mode selection wiring. It is worth noting that the rated voltage of the solenoid valve coil must be controlled within ±10% of the output voltage of the controller, and the equipment should be avoided from being exposed to salt spray, acid corrosion or conductive dust environment. Rain and impact protection measures must be taken during installation.

In terms of operation process, users can program parameters through the panel buttons of the pulse controller TKZM-06, such as adjusting advanced parameters such as the stabilization time before injection and the chamber interval. Taking the modification of pulse width as an example, press and hold the S1 key to enter the parameter selection interface, and use the S2/S3 key to increase or decrease the value. The system will automatically save and switch to the main program after 10 seconds of no operation. During maintenance, the tightness of the terminal blocks must be checked regularly. If a fuse blows, the matching of the solenoid valve coil must be checked first. It is strictly forbidden to use alternative fuses exceeding 1A.

The pulse controller TKZM-06, the solenoid pulse valve, the spray pipe, and the air bag together form a pulse spray system. The timed pulse release of compressed air forms an instantaneous positive pressure shock, which causes the bag to expand and shake off the dust. During the cleaning process, the system maintains the continuous operation of the dust collector. Only a pulse width of 0.01-99 seconds is required to complete efficient cleaning. The pause time between two pulse cycles can be adjusted through the cycle interval to achieve energy consumption optimization. This design enables the dust collector to maintain stable resistance without interrupting filtration, significantly improving processing efficiency and filter bag service life.

When looking for high-quality, reliable pulse controllers, YOYIK is undoubtedly a choice worth considering. The company specializes in providing a variety of power equipment including steam turbine accessories, and has won wide acclaim for its high-quality products and services. For more information or inquiries, please contact the customer service below:
