I. What role does filter element LH0660D10BN3HC play in the hydraulic oil system of power plants?

Filter element LH0660D10BN3HC can be called the “clean guard” of the hydraulic oil system of power plants. The operation of various equipment in power plants relies on the hydraulic oil system to provide power, and the long-term operation of the equipment will produce metal debris, dust impurities, sludge and other pollutants mixed into the hydraulic oil. If these impurities are not filtered, they will seriously wear key components such as hydraulic pumps, valves, and cylinders, reducing the service life and operating efficiency of the equipment. With high-precision filtration of 10μm, the filter element can intercept more than 99% of fine particles, purify hydraulic oil, ensure the cleanliness of the oil in the system, and lay a solid foundation for the stable operation of the equipment.

II. What are the advantages of its structure and material?

1. Filter layer material: filter element LH0660D10BN3HC using advanced glass fiber. On the one hand, it has a strong dirt holding capacity and can accommodate a large number of impurities, reducing the frequency of replacement; on the other hand, it has good chemical stability and can withstand additives and corrosive substances in hydraulic oil. The filtering performance is stable in long-term use, and while ensuring the filtering accuracy, it provides a large oil passage area, reduces the oil passage resistance, and reduces the system energy loss.

2. Skeleton material: Carbon steel is selected. Carbon steel has high strength and good deformation resistance. When the hydraulic system is running and the oil presses on the filter element, it can support the filter layer, prevent the filter element from deforming and breaking under high pressure, and ensure the normal operation of the filter element.

3. Sealing material: The sealing part is made of high-performance rubber, which has good oil resistance and sealing, effectively prevents oil leakage, and maintains a stable filtering effect.

III. Can the working parameters of the filter element adapt to the complex working conditions of the power plant?

1. Working temperature: Yes. It can operate stably in a wide temperature range of – 30℃ to 110℃. The operating environment of power plant equipment is complex, and the hydraulic oil temperature fluctuates with equipment load, operating time, and ambient temperature. Whether it is low temperature during winter startup or high temperature during full load in summer, the filter element can maintain good filtering performance.

2. Working pressure: The filter element can withstand a pressure of up to 21MPa, which can meet the pressure requirements of the hydraulic oil system of the power plant under different working conditions. Whether the high-pressure oil pump outputs high-pressure oil or the system pressure fluctuates, it can stably filter the oil to ensure stable transmission of system pressure.

IV. Is it convenient to maintain the filter element LH0660D10BN3HC? Are there any safety measures?

1. Convenience of maintenance: The design fully considers the convenience of maintenance, the structure is reasonable, and the installation and disassembly are simple. Maintenance personnel can quickly replace the filter element, greatly shorten the equipment downtime maintenance time, and improve the production efficiency of the power plant.

2. Early warning and safety guarantee: Equipped with an advanced filter element pollution transmitter, when the filter element is blocked by pollutants and the oil inlet pressure reaches 0.35MPa, the transmitter sends a signal to remind replacement or maintenance. There is also a bypass valve at the bottom of the filter element. When the filter element is severely clogged and the transmitter alarms but the machine cannot be shut down immediately for processing, the bypass valve will automatically open at an opening pressure of 0.4MPa to ensure that the hydraulic system continues to operate and avoid system failures due to filter element clogs, providing double protection for the safe production of the power plant.

By the way, we have been supplying spare parts for power plants around the world for 20 years, and we have rich experience and hope to be of service to you. Looking forward to hearing from you. My contact information is as follows:
